Television sets

The following Television sets have been owned and used by Hans Sundgren.

Samsung The Frame LS03D 4K QLED, 43”
Samsung The Frame

Image courtesy: Samsung

Technical data

  • DVB-T2CS2
  • QLED LCD 4096×2160
  • Stereo, 20 W
  • HDMI, USB Composite, SPDIF
  • IR remote control
  • 220–240 V AC, 53–112 W
  • 970×558×20 mm
  • 8.6 kg

November 2024

Hans has used the small 19" TV standing on the coffe table in the living room, for 13 years. The HDMI-cable and mains cable are laying on the floor and are sometime disturbing. Therefore he decides to upgrade to a large wall mounted TV.

The Samsung "The Frame" seems like a good choice. It is available in several sizes up to 85". Hans want s to connect the screen to the separate box in the entrance and therefore he needs a 15 meter fiber optic cable that he buys from Dustin. That cable only supports sizes to 43" that he therefore buys.

2024-11-17 Orderbekräftelse

SEK 11990

Good

  • High image quality.
  • Small enough to be stationed on the dining room table.

Bad

  • Small distortion in the image compared to a CRT type television.
  • ???

November 2024

The TV is delivered and fixed to the concrete wall by Smartify 2024-11-17.

Signal via HDMI

The distribution of the TV signal is changed from antenna connection to a Telia TV-box connected to LAN. Therefore the long antenna cable in the living room is replaced by a shorter HDMI-cable to the TV-box in the entrance.

Sony KDL 19BX200, 19"
Sony KDL 19BX200

Image courtesy: Sony

Technical data

  • VHF/UHF/HYPER/CATV and DVB-T
  • CCFL LCD 1366×768
  • Stereo, 2×3 W
  • HDMI, D-Sub, USB 2.0, RF, Composite, PCMCIA, SCART and 3,5 mm audio
  • IR remote control
  • 220–240 V AC, 27 W
  • 457×311×63 mm
  • 4.5 kg

May 2011

Hans will have a visitor staying over for some time, and the 7" TV is probably too small for 2 persons to watch simulataneously, therefore a larger screen is needed. After investigating all stores, the Sony is selected due to the image quality, brand and pleasant white color.

SEK Xxxx

Good

  • High image quality.
  • Small enough to be stationed on the dining room table.

Bad

  • Small distortion in the image compared to a CRT type television.
  • ???

Signal vi RF antenna input

Rear connections

The back of the TV has all connections that are needed. Although Hans uses only the mains power supply and antenna connection to the TV-socket in the appartment.

Signal via HDMI

The distribution of the TV signal is changed from antenna connection to a Telia TV-box connected to LAN. Therefore the long antenna cable in the living room is replaced by a shorter HDMI-cable to the TV-box in the entrance.

Denver® DFT-709, 7"
Denver DFT-709

Image courtesy: Denver

Technical data
  • VHF/UHF, 255 preset channels
  • TFT-LCD 1440×234, xxx' colors
  • Mono, 0.3 W
  • Telescopic antenna + external
  • Audio/video input
  • IR remote control
  • 12 V DC, 10 W
  • Adapter for 230 V AC
  • Car cable
  • Battery compartment 10xAA
  • 216×144×33 mm
  • 622 g
Documents

pdf Brochure

pdf, restriced Instruction manual

September 2005

Hans needs a new TV after the Philips stopped working. He don't need a large size screen, but likes wide-screen TV. This small one from Clas Ohlson was perfect.

SEK 1249

Good
  • The small size
  • Environmental friendly, only 10 W power consumption
Bad
  • Not so good image and sound quality
  • No SCART connector

2006-03-31: Watching film on Tessingatan

Viewing TV

It is 21:07 and Hans has just started to watch Die Hard 2 on TV3. The signal was sent out on the appartment cable TV network. The signal passed two boxes before arriving at the composite antenna input on the TV set. First the composite signal from the cable outlet goes into the TV2-network box. The output from the box is then fed via SCART to a separate converter with composite output for the TV set.

Philips Xxxx, 17"

Image courtesy: Philips

Technical data
  • Xxxx
Documents

pdf, restriced None

Xxxx 19xx

Xxxxxx



Good
  • Good remote control
  • Good image quality
Bad
  • Plastic appearance
  • Small controls on the TV itself



Mark DC-4588, 4.5"

Technical data

  • Black and white
  • Integrated AM/FM radio
  • AM: 530–1600 kHz
  • FM: 88–108 MHz
  • UHF: 21–69
  • VHF: 2–12
  • Power supply: 12 V DC, 9 W
  • Battery power: 10 batteries size C
  • Dimensions: 18×12×10 cm
  • Weight: 1.1 kg

Documents

  • None

19xx

Hans moves to a small appartment and needs a small TV. This one is perfect.

xxxxx.

Good

  • Small size, easy to place.
  • Can run on internal batteries.

Bad

  • Difficult to get a good reception using the rod antenna.
  • Tricky to change channel using the analog dial.

End of life January 2023

The TV has been useless after that the analog broadcast was closed down in year 2007. Left for recycling 2023-01-02.
